DAICHIN WELDING ELETRODE NO.DKD 11
Charecteristics
● R & D for using onto cold press mold such as SKD 11 , SKD 61 (JIS), etc.
● Buildup and repair forging dies and punch unit.
● Especially for hard facing,cutting blades without preheat and subject to TD, TIC coating such as Blanking Dies, Gauge Cold Triming Dies, Plastic Mold Drawing Dies, Punch, Slitter Forming Dies, Thread Rolling Dies.
Mechanical Properties
Hardness As welded : 38 ~ 42 HRC
Cooled down and tempered at 200°C : 58~62 HRC
